Wind up and down
The high-body and wide-body reflector form wind momentum; stability, bottom and stabilization conditions are assessed.
CE · Gas patio heater
CE conformity for Gas patio heater
For Gas patio heater, the applicable CE scope is determined from intended use, energy sources, safety architecture and target market. The risk assessment, technical file, testing and conformity route must be verified against the actual model.
Use itVery well ventilated area open or defined in instructions
FuelTypically an LPG tube, defined regulator and hose
HeatingTop briller, diffuser surface and wide reflector
StabilityHeavy foundation, rolling safety and optional fixing
Direct response to the scope
CE conformity for Gas patio heater — Define the product boundary first
In an umbrella-type terrace heater, the LPG tube is placed in the bottom compartment, the gas reaches the upper briller from a long pipe, and directs the reflector beam downward. The bottom weight, body height, and reflector area determine the tendency to roll under wind load.
The burner is exposed to the wind and gas can cause a burning mixture. Fire control, ignition, low and high pressure behaviour, rain effect, injector clogging, and burn resistance are tested in different settings. Since the reflector, protective grid, and upper body are very hot, the user's normal access is clearly indicated, the distance to the nearest tent, umbrella, furniture, and plants is closed. Warnings of possible misuse, which can be caused by the burning of a fire control, a closed balcony, or a temporarily transported forecast, are not left with only a small pictogram; they are clearly described on the product and packaging.
The pipe partition must be sufficiently ventilated, the hose must be protected from a hot surface and sharp edge, the connection to the regulator must conform to the gas and pressure regime of the target country. Different LPG pipe dimensions can affect the closure of the door, the center of gravity and the tube curve. The manufacturer limits the pipe size and maximum full weight allowed. The pipe or regulator's conformity markings are finite. The conformity markings of the pipe or regulator do not replace the GAR evaluation of the product. The product of the pressure tube itself is a separate product from the GAR process of the thermal insulator. The approved type of the thermal insulator is a product of the GAR process. The approved type of the selected GAR module assesses the type of the equipment and the output of the product. The manufacturer may use the appropriate key and the appropriate safety markings and hazard markings, and may not be subject to the user's approval, but may be subject to the appropriate manufacturing instructions, specifications, specifications, or specifications.
Product profile
Technical features that change the evaluation
The following data shows why even models with the same product name can change the path of conformity.
Use itVery well ventilated area open or defined in instructions
FuelTypically an LPG tube, defined regulator and hose
HeatingTop briller, diffuser surface and wide reflector
StabilityHeavy foundation, rolling safety and optional fixing
Check it outFire, fire control and power setup
VariantBody height, reflector, power, tube section and gas set
Risk architecture
The main dangers to be addressed in the file
The protective, control and verification approach shall be based on the actual product cycle.
Fire extinguishing
Wind or low pressure tube can extinguish the flame; fire control must safely cut off the gas flow.
Use in closed space
The combustion products and oxygen consumption can be dangerous; the environment of use is clearly limited in the product, packaging and instructions.
Gas accumulation in the tube section
The leakage can be collected in an inadequately ventilated ceiling; openings, pipeline and connection access are examined.
Hot spotlight and grille
The user or nearby tent can approach a very hot upper section, which confirms protection, openness and warming surface warnings.
Wrong regulator
The regulator that is not compatible with the target gas pressure creates excessive force or unstable combustion; country sets are defined in a traceable manner.
The conditional law matrix
When will the regulation take effect?
A single product name doesn't give the same answer for all models.
| The subject | The situation | Product-based evaluation |
|---|---|---|
| GAR 2016/426 | YES, YES | The heating device for the outdoor/local area is included in the gas. |
| Authorized organization | YES, YES | The GAR requires mandatory third party participation in the chosen module. |
| ATEX | NO , NOT AT ALL . | LPG use alone does not make the heater ATEX equipment; explosive atmosphere use is also not applicable if not intended. |
| PED | NO , NOT AT ALL . | The heater's low pressure gas pathway is typically not covered by PED; the separate LPG pipe is subject to its own product/transportation rules. |
| LVD and EMC | IT 'S A MESS . | Technical consideration is given to the variant with electrical ignition, lighting, motor or electronic control. |
| The machine's layout | NO , NOT AT ALL . | The standard fixed terrace heater does not have machine function; if the engine is designed specifically, the decision is re-decided. |
Standard and verification approach
- EN 14543: The basic application is if the product structure fits the scope of the LPG-using umbrella type and unmanned outdoor radiant heaters.
- EN 437: The gas category defines the experimental gas and feed pressure for the target country.
- EN 13611: The gas may be related to the structure of the security and control arrangements.
- EN 16129: If the LPG regulator and associated safety arrangements are provided with the product, it is relevant in terms of the choice of the right type and package coverage.
- EN 16436 series: If the LPG hose assembly is supplied with the product, the relevant section for the selection of materials and connections is also checked.
Important distinction
CE conformity for Gas patio heater — Product conformity is a separate study.
ISO management system certification does not replace product-specific risk analysis, test evidence and compliance file.
The compliance work plan
In what order will the technical preparation proceed?
Define the device and gas set
The body, base, reflector, burner, tube, regulator, hose and target area shall be documented.
Matching country and scope
Gas pressure, connection set, label language and additional electricity if alone are determined by target market.
Risk and experiment plan
Stability, wind, overturning, leakage, combustion, temperature and misuse scenarios are prepared.
GAR organization evaluation
The representative device and technical file shall be submitted to the approved institutional review according to the selected module.
Control of production and market presentation
Critical parts, final tests, packaging alerts, instructions and safe use scenarios are attached to the approved type.
Product records to search for in the technical file
- Product and open-field usage definitions
- Drawings of the body, base and reflector
- Gas pathway, tube and regulator characteristics
- Wind rating with stability
- Risk and legislation matrix
- Gas, combustion, rollover and temperature tests
- Production control plan with critical parts
- Installation, tube replacement, opening and maintenance instructions
They 're the entries for a healthy offer .
- Heating body and reflector size
- Gas category with nominal power
- Ground weight and fixing
- Size of the tube section
- Regulator and hose sets
- Power options
- Target countries, number of models and reports
The stability sample does not give a definite price or completion date until the country-specific LPG sets, model sizes and existing tests are seen; the scope is clarified along with safe use claims.
Internal links
Relevant category and product guides
Compare the top coverage or other similar risk architecture.
Frequently Asked Questions
CE conformity for Gas patio heater — Technical answers about
Can the gas-cooled terrace heater be used on the closed balcony?
Only if adequate ventilation and opening conditions are provided as clearly defined by the manufacturer; a closed balcony or winter garden is generally not considered open space.
Is the rotation key enough to stabilize on its own?
No, the geometry and weight of the floor should prevent the overturning, so the key is an additional function that safely shuts off the remaining risk.
Can every LPG tube be plugged into a device?
No, the manufacturer's permitted size, load weight, connection, regulator and pressure characteristics of the tube should be used.
Does the terrace heater need an ATEX sign?
It is not necessary because the normal open space heater contains only LPG; it is also considered if use in an explosive atmosphere is specifically intended.
Can the reflector be magnified?
The large reflector changes wind load, radiation distribution, upper temperature and balance; its effect on the approved type should be studied.
If the regulator has a separate approval mark, is the device test unnecessary?
No, the regulator's conformity is the input, the actual pressure, the hose, valve, briller and flame behaviour are verified in the finished heater.
