Stroke of the rear mechanism
A forward and backward peak with a wide stroke can deliver a high-energy blow to the person reaching the frontal area, confirming both protective and postural performance.
CE · Weaving loom
CE conformity for Weaving loom
For Weaving loom, the applicable CE scope is determined from intended use, energy sources, safety architecture and target market. The risk assessment, technical file, testing and conformity route must be verified against the actual model.
The texture methodA shuttle, a rapier, an air jet or a water jet
Moving areaTop, garbage carrier, solder-wood leven and edge arrangement
Frequent interventionsWire disconnection, solvent bonding, quality control and levent change
Main releaseHigh-speed noise and vibration
Direct response to the scope
CE conformity for Weaving loom — Define the product boundary first
The dangers of jet, jet, jet, or water jet weaving systems are not the same. The high-speed forward and reverse movement of the rope, pressurized air and noise in the jet, wet environment in the jet, and sliding are different inputs.
During the loose connection, removal of thread rupture and examination of fabric error, the operator may approach the protective area. The main mile and peak movement is measured after the machine stops, compared to the shutter opening time.
Changing heavy solvents and fabric levers can be done by a lifting car or a lifting system. Sitting the mill nest, closing the lock, running the roller, and sticking the worker is not just an operating procedure; it is a matter of designing the machine interface.
Product profile
Technical features that change the evaluation
The following data shows why even models with the same product name can change the path of conformity.
The texture methodA shuttle, a rapier, an air jet or a water jet
Moving areaTop, garbage carrier, solder-wood leven and edge arrangement
Frequent interventionsWire disconnection, solvent bonding, quality control and levent change
Main releaseHigh-speed noise and vibration
Risk architecture
The main dangers to be addressed in the file
The protective, control and verification approach shall be based on the actual product cycle.
Access to Rapier or the screw element
The fast carrier can damage the hand and eye when adjusted or wired.
Don 't crush and run in the levent
During lifting, bed-riding, or locking of a heavy roller, there may be a friction between the worker and the body.
Edge cutters
Small knives working on the edge of the fabric are a low-visibility cutting hazard.
Noise exposure
In a room with more than one desk, total exposure increases, machine emissions are measured, and the reduction and reporting are analyzed at the source.
Fiber and fat accumulation
A layer of fiber combined with a warm surface or electrical fault can increase the fire, providing cleaning access and periodic design data.
The conditional law matrix
When will the regulation take effect?
A single product name doesn't give the same answer for all models.
| The subject | The situation | Product-based evaluation |
|---|---|---|
| The machine's layout | YES, YES | In Turkey, 2006/42/AT is applied for the weaving tray; the next national compliance is confirmed on the date of the first market supply or first service of the tray. Safety of movement and control are jointly examined. |
| EMC | IT 'S A MESS . | EMC scope is assessed in terms of the intended environment; driver and communication patterns affect test requirements. |
| LVD | NO , NOT AT ALL . | The LVD is not applied to machinery as a separate directive; electrical safety objectives are met within the scope of machinery legislation. |
| PED | NO , NOT AT ALL . | The weaving function typically does not include pressure equipment; in an airjet model the compressor's separate equipment limit is assessed. |
| ATEX | IT 'S A MESS . | If the fibre dust is shown to create an explosive atmosphere in the intended environment, the choice of equipment shall be examined. |
| Noise | YES, YES | Emission reduction, measurement and the provision of relevant values in the instruction are subject to assessment. |
Standard and verification approach
- EN ISO 11111-1: The textile machine family sets common safety principles.
- EN ISO 11111-6: It is used in the fabrication machinery to assess the risks of the weaving workstation.
- EN ISO 12100: It sets the limits of the machine and the risk analysis of all use phases.
- EN ISO 13855: It can be applied to associate the duration of the dangerous movement with the opening or sensing arrangement.
- EN ISO 13849-1 and -2: The lock lock allows for verification of safe settings and restart barrier functions.
- EN 60204-1: The electrical equipment is selected within the scope of the protection, control and test items.
Important distinction
CE conformity for Weaving loom — Product conformity is a separate study.
ISO management system certification does not replace product-specific risk analysis, test evidence and compliance file.
The compliance work plan
In what order will the technical preparation proceed?
Defining the desktop variant
The texture method, width, speed, leverage weight and options are all collected in a single configuration list.
Operator task analysis
The disconnection, bonding, sampling, cleaning and levent exchange movements are examined on the field.
Protection and setting mode
The covers, access distances, low speed and holding functions are designed as a risk.
Measurement and function test
The time of the stand, noise, electrical and safety circuit behaviour are recorded on the final machine.
Delivery file
The installation, levent transport, setup, maintenance and reporting information is matched with the model label.
Product records to search for in the technical file
- General location of the counter
- Movement and danger zone drawings
- Risk assessment
- Protector-lock details
- Electrical and pneumatic schemes
- Recorded duration of the session
- Verify the security function
- Noise measurement report
- Install-render-levent change instructions
- In Turkey, 2006/42/AT requires an AT Statement of Conformity in the textile file. For textiles, the EU/AEA includes 2006/42/EC on 19 hob 2027; the textile record uses the AT/EC Statement of Conformity. This textile desk is applied to the EU Statement of Conformity under (EU) 2023/1230 from 20 hob 2027.
They 're the entries for a healthy offer .
- Texturing method and model
- Maximum speed and work width
- Size and weight of levent
- Protector-locking mode
- Engine-driver-control list
- Air or water auxiliary system
- Current testing and initial market offer or service plan
Desk width, speed variants, weaving technology, automatic leverage system, and existing validations affect the working calendar.
Internal links
Relevant category and product guides
Compare the top coverage or other similar risk architecture.
Frequently Asked Questions
CE conformity for Weaving loom — Technical answers about
Can the summit be reached immediately when the platform is stopped?
Actual stand time is measured and compared to the time of access of the protective opening and lock or brake solution if the failure continues.
Is low enough speed to tie the rope?
The numerical value of the low speed is evaluated together with the holding and other controls being disabled.
Does the air jet stand fit into the compressor's CE file?
The compressor can be a separate machine, and the pressure, connection, and air safety interface required by the desk is in the file.
Is the Levent a separate equipment?
It could be a simple handheld device or a propelled lifting machine, and the function and safety link determines the scope of the decision.
Is the noise meter in a hall a reporting machine?
The purpose of the facility exposure measurement and the machine emission measurement is different.
Is the electronic pattern software kept in the technical file?
The version, parameter, and change records that affect the secure behavior are tracked in the file.
Technical scope and offer
CE conformity for Weaving loom — Let us clarify your technical file together.
Share the model of the machine or device, the location of use and the basic technical data. The Kayra Patent explains the path to be followed for scope analysis, technical preparation, test plan and, where necessary, approved organization coordination.
Final inspection of content and technical scope: 20 August 2026The official bases: European Commission Machinery · EUR-Lex — EU 2023/1230
