Contact with the needle and clip chain
The edge of the fabric can be between the hand, needle or moving clip when feeding.
CE · Stenter machine
CE conformity for Stenter machine
For Stenter machine, the applicable CE scope is determined from intended use, energy sources, safety architecture and target market. The risk assessment, technical file, testing and conformity route must be verified against the actual model.
Main lineInlet-outlet, needle/clips chain, drying cabins, cooling and exit
HeatingGas burner, thermal oil, steam or electricity
Critical eventAirflow loss, extreme heat, fiber-chemical fire and chain jamming
The interfaceExhaust, emission reduction, heat recovery and building ventilation
Direct response to the scope
CE conformity for Stenter machine — Define the product boundary first
The fabric is opened at the entrance, the edges are held onto needles or clips, the backs are passed through hot cabins, and the exit is cooled and wrapped. The feeding stairs, the mesh, the chain tooth, the clip openers and the exit roller form a large number of compression points.
High temperature in the dryer, fan movement and the residual finish with accumulated fiber increase the fire load. Filter or channel clogging can raise the temperature while lowering airflow. In extreme temperatures, fan failure, burner flame loss and emergency shutdown scenarios, engineering analysis determines which equipment will continue to operate immediately, which for a controlled period.
The GAR coverage of the process device used in the gas or LPG used in the gas is examined separately. If solvent finishes or flammable vapours are present, ventilation and ATEX distribution are required; each gas is not automatic ATEX. Changes in pressure, control and fire behaviour against the heat recovery unit, electrostatic filter or barrel cleaning system are reflected in the technical file when added later.
Product profile
Technical features that change the evaluation
The following data shows why even models with the same product name can change the path of conformity.
Main lineInlet-outlet, needle/clips chain, drying cabins, cooling and exit
HeatingGas burner, thermal oil, steam or electricity
Critical eventAirflow loss, extreme heat, fiber-chemical fire and chain jamming
The interfaceExhaust, emission reduction, heat recovery and building ventilation
Risk architecture
The main dangers to be addressed in the file
The protective, control and verification approach shall be based on the actual product cycle.
The Merdane and the Chain
The input-output cylinders and the gear rotations form a large number of intercept points along the long line.
Hot cabin and surface
When the door, duct, or maintenance lid is opened, hot air and metal surface can cause burns.
Brush failure
Flame loss can lead to low air or failed ignition gas buildup, confirming the combustion order and monitoring functions.
Fiber-chemical fire
The filter, the duct and the cabin residue can be burned at high temperatures, with cleanliness access, sensing and safe closure planned.
Harmful steam and ATEX
The finished recipe can produce harmful or flammable vapor, depending on the leakage, leakage and distribution material.
The conditional law matrix
When will the regulation take effect?
A single product name doesn't give the same answer for all models.
| The subject | The situation | Product-based evaluation |
|---|---|---|
| The machine's layout | YES, YES | In Turkey, 2006/42/AT is applied for ramose; the next national compliance is confirmed on the date of the ramose's first market offer or first service. Chain and integrated control are examined in this context. |
| GAR | IT 'S A MESS . | The scope is examined including the exception of industrial processes; if GAR is applied, the approved establishment process in the appropriate module is also carried out. |
| ATEX | IT 'S A MESS . | The flammable finish steam or fibre-powder may be used if available for intended use. |
| EMC | IT 'S A MESS . | EMC scope is assessed in terms of the intended environment; driver and communication patterns affect test requirements. |
| LVD | NO , NOT AT ALL . | The LVD is not applied to machinery as a separate directive; electrical safety objectives are met within the scope of machinery legislation. |
| PED | IT 'S A MESS . | The scope shall be measured according to the PS-volume data in the thermal oil, steam or pressure relief equipment. |
Standard and verification approach
- EN ISO 11111-1: The textile machine provides a family's common risk reduction provision.
- EN ISO 11111-7: It is the section for special hazards in drying and finishing machines.
- EN 746-2: Applicability in terms of combustion and fuel systems in industrial thermo-process equipment is assessed.
- EN ISO 12100: It collects mechanical, thermal, chemical and fire scenarios in a common risk method.
- EN ISO 13849-1 and -2: It can be used for fan flow, temperature limit, door lock and brush safety functions.
- EN 60204-1: The power supply of the long machine is used extensively for control areas and tests.
Important distinction
CE conformity for Stenter machine — Product conformity is a separate study.
ISO management system certification does not replace product-specific risk analysis, test evidence and compliance file.
The compliance work plan
In what order will the technical preparation proceed?
Line and prescription boundary
The work width, speed, temperature, finishing materials and type of heating are defined.
Mechanical access analysis
The operator's duties are examined at the needle-clips, chain, staircase, fan and maintenance doors.
The fire-burning scenario
Flame loss, air conditioning, extreme heat, filter clogging and emergency stand order are designed.
Verify the field
The values of position, temperature, flow, gas safety, electricity and exhaust are taken for the functional test.
File and operating conditions
The box, cleaning and prescription limit is completed; if GAR is applied, approved institutional documents are separated from machine records.
Product records to search for in the technical file
- The location of the line
- Process flow and risk assessment
- Chain-curtain protective drawings
- Heating-gas-air schemes
- Electrical and control circuits
- Fire and fire safety function records
- ATEX-PED-GAR scope decisions
- If GAR is applied, certified organization documents and identity records
- Cleaning-use-maintenance instructions
- In Turkey, 2006/42/AT requires an AT Statement of Conformity in the rational file. For rational is the EU/AEA including 19 hob 2027 2006/42/EC; the rational register uses the AT/EC Statement of Conformity. This rational line goes into the EU Statement of Conformity from 20 hob 2027 (EU) 2023/1230.
They 're the entries for a healthy offer .
- Working width and line speed
- Maximum room temperature and number of cabins
- Heating and fuel types
- Finishing chemicals
- Exhaust-filter heat recovery
- Control and security components
- Target market with existing tests
The cabin length, heating technology, chemical prescription, emission purification linkage and the state of fire tests determine the scope.
Internal links
Relevant category and product guides
Compare the top coverage or other similar risk architecture.
Frequently Asked Questions
CE conformity for Stenter machine — Technical answers about
What is the basis for the GAR's decision on the smoke-burning system?
The purpose of industrial processes is to study the briller and system design with the exception of scope.
Should the fans be shut down immediately at the emergency stop?
Controlled ventilation may be required in some fire or no longer heat scenarios.
How does solvent-free finishing affect the ATEX decision?
If there is no burning steam, the result may be different; the fiber powder and other substances are re-examined.
Can the heat recovery unit be added later?
It can be added but the pressure, temperature, friction and fire behaviour against exhaust can change.
How should the brush and fan behave when the cabin door opens?
Fan power, hot air, chain motion and restart are also assessed.
Can each module of the rhyming line be reported separately?
Documentation of independent modules may be found; integrated assessment of end-line interface risks due to common fabric flow and controls also requires.
Technical scope and offer
CE conformity for Stenter machine — Let us clarify your technical file together.
Share the model of the machine or device, the location of use and the basic technical data. The Kayra Patent explains the path to be followed for scope analysis, technical preparation, test plan and, where necessary, approved organization coordination.
Final inspection of content and technical scope: 20 August 2026The official bases: European Commission Machinery · EUR-Lex — EU 2023/1230
