Wrap and wrap
Rotating mills, coils and traction cylinders can hold loose clothing or hand, balancing the visibility of the process with the range of access.
CE · Textile and garment machinery
CE conformity for Textile and garment machinery
For Textile and garment machinery, the applicable CE scope is determined from intended use, energy sources, safety architecture and target market. The risk assessment, technical file, testing and conformity route must be verified against the actual model.
I 'm going to catch it .Machinery for weaving, weaving, ageing, drying and training
The main risk setFast movement, embrace, crush, temperature, chemical and fire
Line queryCommon fabric flow and integrated machine limit in the central controller
The transitionThe transition from 2006/42/EC in Turkey to 2023/1230 will take place on 20 hob 2027 (EU)
Direct response to the scope
CE conformity for Textile and garment machinery — Define the product boundary first
In textile production, the operator often approaches the machine not only at the start and stop, but during thread breaking, fabric direction, coil change, cleaning and quality control. This frequent intervention increases the likelihood of access to the dangerous areas that theoretically appear to be closed.
In Turkey, the 2026 proposal is based on the file and the AT Compliance Statement prepared under 2006/42/AT. In the EU and EEA, 2006/42/EC is valid until the end of 19 hob 2027; (EU) 2023/1230 comes into force on 20 hob 2027. The national compliance regulation of the machine presented to Turkey is also confirmed on the date of first market offer or first service delivery.
In textile painting and tanning processes, mechanical hazards include hot surface, steam, pressure, burning or harmful chemical, exhaust air, and fire scenarios. Prescriptions or burning finish materials containing solvent may require an assessment of explosive atmosphere. PED classification in pressure painting body, combustion safety in gas-heated drying section, and to the appropriate extent other product legislation is coordinated with the machine file.
The result of a safe design on a textile line is not measured by the number of protectors alone. The ability to see the thread or fabric flow, ergonomic access to the set points, the movement left after the machine stops, simultaneous start of different sections, and the understanding of audio-visual alerts are confirmed together. The effect of emergency stops along the line, which section it stops, and the result of the controlled position on the fabric tension are not accepted without testing.
Product boundaries
How do you sort out the right product line in this category?
Name similarity alone is not sufficient; the energy source, intended use, and safety architecture are read together.
| Product or limit | The distinguishing feature | The relevance of the results |
|---|---|---|
| How often does the operator interfere with the process? | The access solution is selected by observing the movements of thread binding, fabric straightening and sampling on real-time. | |
| Any energy or movement left? | The post-positioning behaviour of the steering wheel, cylinder, fan and tensioned fabric is included in the safe access period. | |
| Is the process under pressure? | PED analysis is performed for the painting bowl and associated safety accessories with data on PS, volume, fluidity and temperature. | |
| Is there any chemical burning? | ATEX equipment is not decided without material safety information, aeration and localisation data. | |
| Is the machine part of a line? | The position, speed reference and emergency stop exchange between the upstream and downstream machines are documented. | |
| Can you set it up remotely? | Unauthorized change and the possibility of unexpected startup is managed by an access architecture separate from security functions. |
Risk architecture
The main dangers to be addressed in the file
The protective, control and verification approach shall be based on the actual product cycle.
Back and forth mechanism
The weave buffer, or moving car, creates a wide hazard area in unexpected environments.
Injury to the needle and cutting element
Replica needles, edge cutters, and automatic thread knives may be accessed during setup. Limited motion is designed for service mode.
Chemical and hot bath
The painting prescription, steam and pressurized hot liquid, carries the risk of burning, inhalation and uncontrolled discharge.
Fire in the drying area
The feathers, oil, chemical residue and high temperature can be burned in the ramus. Filtration, temperature limit and emergency scenario are tested together.
Noise and ergonomics
Heavy levent or coil change with constant noise of high-speed desks is a long-term operating risk.
The conditional law matrix
When will the regulation take effect?
A single product name doesn't give the same answer for all models.
| The subject | The situation | Product-based evaluation |
|---|---|---|
| The machine's layout | YES, YES | In Turkey, 2006/42/AT applies to textile machinery; the next national compliance is confirmed on the date of the first market supply or first service of the textile unit. Mechanical and control safety is assessed in this framework. |
| EMC | IT 'S A MESS . | EMC scope is assessed in terms of the intended environment; driver and communication patterns affect test requirements. |
| LVD | NO , NOT AT ALL . | The LVD is not applied to machinery as a separate directive; electrical safety objectives are met within the scope of machinery legislation. |
| PED | IT 'S A MESS . | Classification if the PS bar exceeds 0.5 bar in the painting or finish tray; it is done with volume, fluid group and temperature data. |
| ATEX | IT 'S A MESS . | Product category shall be determined if combustible solvent, fibre dust or gas atmosphere are present in the intended use of the equipment. |
| Gas heating | IT 'S A MESS . | The relevant scope shall be determined separately, including for the industrial process exceptions for the ramose briller and the combustion system. |
Standard and verification approach
- EN ISO 12100: Machine limits form the common basis for use stages and risk reduction decisions.
- EN ISO 11111-1: It explains common safety requirements for textile machinery and how to use family-owned parts.
- EN ISO 11111-6: It is used in the assessment of threats to weaving and sewing equipment in textile manufacturing machinery.
- EN ISO 11111-7: The section is applied for painting, printing, training and related processing machinery specific risks.
- EN ISO 13849-1 and -2: The cover lock supports performance and verification of control functions such as safe positioning and speed monitoring.
- EN 60204-1: If the electrical equipment is included, the materials applicable to the protection, control and test arrangements shall be selected.
Important distinction
CE conformity for Textile and garment machinery — Product conformity is a separate study.
ISO management system certification does not replace product-specific risk analysis, test evidence and compliance file.
The compliance work plan
In what order will the technical preparation proceed?
Do not remove the production script
The route of the fabric or thread, operator interventions, prescription change and maintenance work are processed into a process map.
Hazardous zone and energy analysis
The movement, heat, pressure, chemical, pneumatic and stored voltage sources are marked on the machine.
Functional security design
The safety performance required for protective opening, emergency positioning and cross-line signals is determined.
Measurement and field verification
Electricity, standby time, noise, temperature and, where necessary, emission or ventilation data are recorded.
Close the file and the instructions
The latest machine configuration, secure setup methods and report information are consistent with each other.
Product records to search for in the technical file
- Machine location and fabric-wire flow diagram
- Risk assessment
- Mechanical protective drawings
- Electrical, pneumatic and heating schemes
- Security function accounts and tests
- Access distance records for duration of session
- PED or ATEX scope
- Noise and temperature measurements
- Installation, setup, cleaning and maintenance instructions
- In Turkey, 2006/42/AT requires an AT Declaration of Conformity in the textile file. For textiles, the EU/AEA includes 2006/42/EC on 19 hob 2027; the textile register uses the AT/EC Declaration of Conformity. This textile unit passes into the EU Declaration of Conformity from 20 hob 2027 (EU) 2023/1230 under the date of legal trigger, first market offer or first service in a textile machine.
They 're the entries for a healthy offer .
- Machine type and work width
- Maximum production speed
- Thread or fabric process
- Chemical, temperature and pressure values
- List of engine drivers
- Line connections and location
- Current drawing, testing and risk analysis
The scope of the assessment varies according to the number of desks, speed variants, pressure or heating modules, line integration and field tests.
Internal links
Relevant category and product guides
Compare the top coverage or other similar risk architecture.
Frequently Asked Questions
CE conformity for Textile and garment machinery — Technical answers about
Does adding automation to the old weaving desk require a new C.I.?
The change is technically examined whether it significantly affects the intended use, speed or safety functions of the machine.
Is PED always used on the painting machine?
No, the permitted pressure, volume, fluid group and design characteristics of the equipment determine the classification, and the results may not be the same for open-air machines.
What are the appropriate scope when the ramus is blistered?
The combustion system, the purpose of the process and the scope of the device are also examined.
Can the guard be turned on when the rope breaks?
The method of access is designated, so when the protector is turned on, the dangerous movement must be stopped safely and unexpected restarts prevented.
What noise information should be provided in a textile machine?
The relevant emission values are determined by appropriate measurement methods and reported in the instructions, while the assessment of the facility's personal exposure is the sole responsibility of the undertaking.
Can the CE marking cover the entire textile line?
If the machines working together under common control form an integrated machine, an additional line-level evaluation can be made.
Technical scope and offer
CE conformity for Textile and garment machinery — Let us clarify your technical file together.
Share the model of the machine or device, the location of use and the basic technical data. The Kayra Patent explains the path to be followed for scope analysis, technical preparation, test plan and, where necessary, approved organization coordination.
