Pressure drop at the simultaneous load
All the brillers are on, and the flame at the endpoints can be weakened, and the manifold and regulator capacity is verified.
CE · Professional gas range cooker
CE conformity for Professional gas range cooker
For Professional gas range cooker, the applicable CE scope is determined from intended use, energy sources, safety architecture and target market. The risk assessment, technical file, testing and conformity route must be verified against the actual model.
FunctionCombination of top oven/single piece hot plate with low-gas oven
Use itRestaurant, hotel and community kitchen
Gas systemCommon input, manifold and independent brush controls
EliminationDesign-based management of oven and oven combustion products
Direct response to the scope
CE conformity for Professional gas range cooker — Define the product boundary first
The top of the cooker can have open brillers or a single piece of hot plate (solid ball), gas oven at the bottom. The quick load change of the hob eyes and the long operation of the oven under thermostat control share the same gas path. When all functions are open, the manifold pressure, flame stability and body temperatures can reach the most negative state.
The oven door opening, closing the top surface of the large pot or changing the combustion air of the drum pull can be a simple task for the user to understand which brush a button controls; the associated gas path should be securely closed when the flame is extinguished. The oven thermostat, the top oven faucets, the pilots and, if any, the electric ignition are marked so as not to be mixed during maintenance.
The cousin family can have four, six or eight eyes; different oven volume and power options. When the family is set up, the total load, beam cut, manifold diameter and air clearance are compared alongside the common parts. If the target country gas categories change, the injector, setting and label matrix are prepared.
Product profile
Technical features that change the evaluation
The following data shows why even models with the same product name can change the path of conformity.
FunctionCombination of top oven/single piece hot plate with low-gas oven
Use itRestaurant, hotel and community kitchen
Gas systemCommon input, manifold and independent brush controls
EliminationDesign-based management of oven and oven combustion products
Family variableNumber of eyes, volume of oven, total strength and size of body
OptionElectric ignition, fan oven or pilot system
Risk architecture
The main dangers to be addressed in the file
The protective, control and verification approach shall be based on the actual product cycle.
Late firing in the oven
The shut-off volume shall be tested for gas disconnection and safe restart behaviour after failure to fire.
The controller is confusing
Numerous buttons can cause the wrong briller to open; location and permanent markings are evaluated.
Heat accumulation in the body
Long-term operation of the upper and lower functions can increase the temperature of valves, hoses, cables and insulation.
The burning product interaction
The discharge of the oven shall not adversely affect the upper briller air or the operator area.
After cleaning assembly
If the leaked parts of the briller are attached incorrectly, the burn changes; physical locking and instructions reduce the error.
The conditional law matrix
When will the regulation take effect?
A single product name doesn't give the same answer for all models.
| The subject | The situation | Product-based evaluation |
|---|---|---|
| GAR 2016/426 | YES, YES | It's a general professional kitchen appliance. |
| Authorized organization | YES, YES | Type and serial production conformity shall be carried out by a third party according to GAR modules. |
| The machine's layout | IT 'S A MESS . | The scope of the change in the EU/EEA is designated if the fan or motor accessory creates dangerous movement. The change in the EU/EEA includes 2006/42/EC, which applies from 20 hob 2027, including (EU) 2023/1230. |
| EMC | IT 'S A MESS . | If there's an electronic ignition or digital control, it's evaluated. |
| PED | NO , NOT AT ALL . | The standard low-pressure gas pathway does not automatically generate PED. |
| ATEX | NO , NOT AT ALL . | Normal kitchen use is not the purpose of explosive device. |
Standard and verification approach
- EN 203-1: It provides general requirements for professional gas-heated kitchen equipment.
- Product sections of EN 203-2: The special sections corresponding to the function of the oven and the hot plate are evaluated together.
- EN 437: It defines the gas category and experimental conditions.
- EN 13611: The thermostat and gas control system functions are considered.
- EN 161: If there's an automatic gas cutter, it's evidence of the product.
Important distinction
CE conformity for Professional gas range cooker — Product conformity is a separate study.
ISO management system certification does not replace product-specific risk analysis, test evidence and compliance file.
The compliance work plan
In what order will the technical preparation proceed?
The function tree
The top brillers, oven, pilot, fan and ignition options are defined in the single device model tree.
Shared system analysis
The interaction of the manifold, total load, air gaps and combustion product pathways is studied.
The most negative sample
The configuration that represents the family is warranted in terms of eye count and oven power.
Type and manufacturing module
The approved organization plans GAR evaluation and production oversight.
Match the file to the report
The label, category, guide, EU Statement of Conformity and list of critical parts are compared for the last time.
Product records to search for in the technical file
- The cousin model tree
- Shared gas cycle diagram
- Drawings of the oven and oven burners
- Total heat load accounts
- Risk assessment
- Leak-free-burn-heat reports
- Tag and control panel markings
- Installation, use and cleaning instructions
They 're the entries for a healthy offer .
- Number of eyes
- Type and size of oven
- Total power
- Gas categories
- Fan/fire options
- Target countries
- Place of production and annual cycle
The hob and the oven variants are studied as a common device.
Internal links
Relevant category and product guides
Compare the top coverage or other similar risk architecture.
Frequently Asked Questions
CE conformity for Professional gas range cooker — Technical answers about
Is a gas cousin one device or two devices?
If it is marketed as a single unit, it is evaluated at the unit level; the specific requirements of the stove and oven are met separately.
Does the oven report cover the top stove?
No, the risks of open burners being fired, burned, solid, and temperature also need to be proven.
Should we retest the eyes when we get more?
The effect is assessed if the total load, manifold pressure, air and temperature change; the current type is not assumed to be automatically covered.
Does the electric fan eliminate the GAR?
No. The function of gas cooking remains within the scope of GAR, and the additional risks of the fan are addressed by appropriate legislation and standards.
How do you manage your cousin's gas conversion?
All briller injectors, settings, category label, service step and final safety check are connected to a defined conversion procedure.
What's the price for your cousin?
The range is calculated by looking at the eye-burning configuration, gas categories, number of countries, available tests, sample and monitoring mode.
Technical scope and offer
CE conformity for Professional gas range cooker — Let us clarify your technical file together.
Share the model of the machine or device, the location of use and the basic technical data. The Kayra Patent explains the path to be followed for scope analysis, technical preparation, test plan and, where necessary, approved organization coordination.
Final inspection of content and technical scope: 20 August 2026The official bases: European Commission Gas burning devices · EUR-Lex — GAR 2016/426
